LOCKWOOD LST8011SSS HEAVY DUTY ADJUSTABLE FOOR SPRING SATIN STAINLESS

LOCKWOOD LST8011SSS FLOOR SPRING (SATIN STAINLESS)

The Lockwood ST8011SSS double action floor closer has been specifically designed to meet the exacting requirements of double or single action pivoted doors with a door leaf weight up to 300kgs.
Innovative design enables onsite flexibility over a wide range of applications.
Designed and manufactured to world class standards which enables the highest possible quality, efficient and reliable performance.
Multi functional designs offer the specifier,stockist or the installer outstanding versatility
and low inventory levels.
Standard Features
Power adjustment
• Turning the screw valve the power can be adjusted from EN size 3-6; closing force ranges
from 24Nm to 60Nm
Adjustable Closing Speed
• Adjustable Closing Speed: Closing 175deg - 15deg,
Latching speed 15deg - 0deg Hold Open
•By setting the HO valve the door can be set to hold open the door at any angle from 85deg
to 170deg opening, to release door manually pull door closed.
Delayed Action
•Adjusting this valve controls the closing time of the door between 170deg - 85deg
Back Check
• Back Check:
The integrated mechanical back check function offers optimum protection for doors and walls

If you require assistance with your selection please contact us either by email or phone.

Strength - 2 - 6 Adjustable
Hold Open - Can be adjusted To Be Either Hold Open Or Non Hold Open
Maximum Door Weight - 300kg
Door Leaf Widths From - 950mm - 1400mm
Maximum Opening Angle - 175deg

Available Finishes - Polished Brass - Polished Stainless - Satin Stainless

FOR RELATED PRODUCTS REFER BOTTOM OF PAGE

Downloadable Files

Downloads

Code	Supplier Part Number	Image	Name	Unit	Application	Function	Product Options	Product Features	Finish	Door Type	Capacity	Strength	Returns Policy	Privacy Policy	Price	Quantity
LWST8011SSS	LST8011SSS		LOCKWOOD LST8011SSS HEAVY DUTY ADJUSTABLE FOOR SPRING SATIN STAINLESS Unit: Each Application: Internal Door,External Door Function: Boardroom Door,Corridor Door,Egress Door,Entry Door,Lift Lobby,Office Door,Smoke Control Door,Stairwell Door,Toilet Lobby,Warehouse Door Product Options: Floor Spring Product Features: Hold Open,Non Hold Open Finish: Satin Stainless Door Type: Aluminium Pivot,Timber Pivot Capacity: 3 - High Usage Strength: 2 to 6 Returns Policy: 20 Percent Surcharge	Each	Internal Door,External Door	Boardroom Door,Corridor Door,Egress Door,Entry Door,Lift Lobby,Office Door,Smoke Control Door,Stairwell Door,Toilet Lobby,Warehouse Door	Floor Spring	Hold Open,Non Hold Open	Satin Stainless	Aluminium Pivot,Timber Pivot	3 - High Usage	2 to 6	20 Percent Surcharge	20 Percent Surcharge	$1,670.60 (exc GST)	Quantity:
