D&D SURECLOSE® CONCEALFIT
Hydraulic Door Closer/Hinge System
D&D SURECLOSE® CONCEALFIT door closer and hinge sets are high-quality, hydraulic units aimed at providing a concealed finish and a highly adjustable self-closing solution. They are ideal for interior and exterior wood, hollow-metal and aluminium doors and frames. When closed, the D&D SURECLOSE® CONCEALFIT system cannot be seen or tampered with. They also provide burglary and vandalism resistance. Superb engineering and patented design allow total concealment of the hinge-closer unit in a remarkably small housing.
The Hinge-Closer is easily adjustable in three dimensions (horizontal, vertical and in/out) for fine positioning and speedy gate alignment. They feature fine controls for primary closing speed, latching speed and backcheck. D&D SURECLOSE® CONCEALFIT is designed for premium flush doors and “invisible” doors. With NO hold-open feature, it opens to, and self-closes from, 125Ë. Steel receivers for hollow-core doors, and routing templates and drill jig for wood gates, are sold separately.
All D&D SURECLOSE® CONCEALFIT housings are made of high-grade aluminium.
Features - Door closer hinge kit - One pair is a closer + hinge combination
- Easily installed internally within the door or wall cavity frame
- Up to 7 different adjustments to ensure perfect installation
- Easily accessed, adjustable closing and latching speed valves
- Secure, safe and quiet operation with no visible moving parts
- The innovative choice of Architects, Engineers and Designers
- ADA (disability) compliant
- Centre mounting
- Self closing hinge from 125º
- Will not hold gates open
- Maximum opening angle 125°
If you require assistance with your selection please contact us either by email or phone. |  | Supplied With Fixings |  | Specifications - Door Application: Interior Door, Front Door, Fire Rated Door, Force Entry Resistant Door, Hotel Door, Theatre Door, Residential Garage Door, Soundproof Door
- Door Type: Self-Closing, Residential and Commercial Flush Doors
- Door Material: Wood Door, Hollow Core Door (Metal, Fibreglass FBG)
- Self-Closing Door Weight: Up to 100kg
- Approximate Door Size: 1220mm maximum width
- Minimum Door Thickness: 40mm
- Vertical Adjustment: +/- 2mm
- Horizontal Adjustment: +/- 1.25mm
- Door Clearance Adjustment from 2mm to 6mm
- Fire Rating: UL/cUL listed (20-minute)
- Fixing Method: Aluminium Screw-On
- Maximum Door Weight: 120kg
- Final Snap Close Actiom: 12° to 0°
|  | Finish - Black FOR RELATED PRODUCTS REFER BOTTOM OF PAGE CLICK TO VIEW ALL BLACK PRODUCTS |
|
