LOCKWOOD 110111-60M ELECTRIC STRIKE POWER TO LOCK

Fail Safe

Trimec ES110 Series Electric Strikes

The ES100/ES110 product range of patented Burglar Resistant Strikes is used with all access control installations where flexibility, security and lower cost is required.

Having a deeper than normal throat, this electric strike will operate with a greater range of locks and offers the same level of security usually provided by more expensive electric locking systems.

Features

• Preset as power to open/power to lock field changeable on site
• Extra strength stainless steel striker latch
• Extra security with 3 hardened locking pins
• Continuously rated solenoid which can be continuously powered
• Optional mounting kit is easy to use
• Easy to use stick-on installation template for faster installations
• IP56 weather resistant
• ES110 suitable for 18 mm (3/4inch ) latch with a 3mm door gap

Face Plate
Stainless steel with round ANSI short style

Technical Data

• Electrical Specification 243mA @ 12Vdc(rated for continuous use)
• Holding strength - 680kg (1499lb)
• Product weight - 162 gms (5.7 oz)
• Shipping size with box - 195 x 48 x 34 ( 7 3/4inch x 1 15/16inch x 1 3/8inch )

Approvals

• Approved to Ul1034(highest level)
• Approved to BS5872
• Electromagnetic compatibility - EN500181 - 1 Exempt
• C-Tick COMPLIANT
• Fire Approval (ES 110)
• Weather Resistant Version (IP56)

If you require assistance with your selection please contact us either by email or phone.

Available Finish - Black
