LOCKWOOD 3784LFSS - 6784LFSS PASSAGE LATCH SATIN STAINLESS

LOCKWOOD 3784LFSS - 6784LFSS PASSAGE LATCH SATIN STAINLESS

  LOCKWOOD 3784LFSS - 5784LFSS PASSAGE LATCH (SATIN STAINLESS)

Long Front Plate Model

The Lockwood Selector range is a comprehensive range of cylinder mortice locks suitable for heavy duty use in industrial and commercial buildings, institutions, clubs, schools, hospitals, hotels and similar buildings.

These locks have various latching functions which can be operated by key or handle outside and by turn knob, key or handle inside.

Outside: Opened by handle at all times.
Inside: Opened by handle at all times.

If you require assistance with your selection please contact us either by email or phone.

Fire.pngSupplied With Fixings

Sets Come Complete With All Items Required For Standard Operation.
PLEASE NOTE THIS ITEM INCLUDES LOCK BODY & (CYLINDER IF  REQUIRED) ONLY DOES NOT INCLUDE HANDLES

Backsets - 23mm - 30mm
Door Thickness Metal Doors - 35mm - 50mm
Door Thickness Timber Doors - 32mm - 50mm
Front Plate Length - 260mm
Front Plate Width - 25mm
Depths - 40mm - 47mm

FOR RELATED PRODUCTS REFER BOTTOM OF PAGE

CLICK TO VIEW ALL STAINLESS STEEL PRODUCTS

Downloadable Files

Downloads

Code Supplier Part Number Image Name Unit Finish Door Type Depth Backset Bolt Throw Returns Policy Privacy Policy Price Quantity
LW3784LFSS LOCKWOOD 3784LFSS PASSAGE LATCH 23MM
  • Unit:
    Kitset
  • Finish:
    Satin Stainless
  • Door Type:
    Aluminium Doors Non Egress,Timber Doors Non Egress
  • Depth:
    40mm
  • Backset:
    23mm
  • Bolt Throw:
    15mm
  • Returns Policy:
    20 Percent Surcharge
 Kitset Satin Stainless Aluminium Doors Non Egress,Timber Doors Non Egress 40mm 23mm 15mm 20 Percent Surcharge 20 Percent Surcharge
Retail: $370.20 (exc GST)
Special: $329.48 (exc GST)
LW4784LFSS LOCKWOOD 4784LFSS PASSAGE LATCH 25.4MM
  • Unit:
    Kitset
  • Finish:
    Satin Stainless
  • Door Type:
    Aluminium Doors Non Egress,Timber Doors Non Egress
  • Depth:
    42.4mm
  • Backset:
    25.4mm
  • Bolt Throw:
    15mm
  • Returns Policy:
    20 Percent Surcharge
 Kitset Satin Stainless Aluminium Doors Non Egress,Timber Doors Non Egress 42.4mm 25.4mm 15mm 20 Percent Surcharge 20 Percent Surcharge
Retail: $438.60 (exc GST)
Special: $390.35 (exc GST)
LW5784LFSS LOCKWOOD 5784LFSS PASSAGE LATCH 30MM
  • Unit:
    Kitset
  • Finish:
    Satin Stainless
  • Door Type:
    Aluminium Doors Non Egress,Timber Doors Non Egress
  • Depth:
    47mm
  • Backset:
    30mm
  • Bolt Throw:
    15mm
  • Returns Policy:
    20 Percent Surcharge
 Kitset Satin Stainless Aluminium Doors Non Egress,Timber Doors Non Egress 47mm 30mm 15mm 20 Percent Surcharge 20 Percent Surcharge
Retail: $370.20 (exc GST)
Special: $329.48 (exc GST)
LW6784LFSS LOCKWOOD 6784LFSS PASSAGE LATCH 38MM
  • Unit:
    Kitset
  • Finish:
    Satin Stainless
  • Door Type:
    Aluminium Doors Egress,Timber Doors Egress
  • Depth:
    55mm
  • Backset:
    38mm
  • Bolt Throw:
    15mm
  • Returns Policy:
    20 Percent Surcharge
 Kitset Satin Stainless Aluminium Doors Egress,Timber Doors Egress 55mm 38mm 15mm 20 Percent Surcharge 20 Percent Surcharge
Retail: $477.30 (exc GST)
Special: $424.80 (exc GST)
